FBR425F Product InformationNon-Metallic Vapor Box with Adjustable Steel Bracket for Double Drywall Ceilings Specification SheetCatalog Page E-mail |
Additional Images
Basic Information
| Part Number | FBR425F |
| Description | Plastic vapor box with adjustable steel bracket for fans and fixtures in new construction. Flange forms a protective barrier against air infiltration. 27.3 cu. in. 70lb fan rated at 24" on center. 110lb fan rated at 16" on center, 90lb rated fixture on 24" on center. 150lb at 16" fixture rated. For double drywall. |
| UPC | 018997722058 |
| Unit Packaging | 5pcs |
| Standard Packaging | 5pcs |
| Country of Origin |  |
| Listing |
|
Physical Information
| Instruction Sheet | FBR425F Instruction Sheet |
| Weight | 1.726 lbs/each |
| Height | 3.408" |
| Width | 6.250" |
| Color |  Black |
| Material(s) | Plastic, Steel |
Technical Information
| Line Drawing | FBR425F Line Drawing |
| Cubic Inches | 27.5 |
| Description | Joint Mount for Fan or Fixture |
| Load Rating | UL Rated at 24" o.c.: 70lb Fan; 90lb Fixture UL Rated at 16" o.c.: 110lb Fan; 150lb Fixture CSA Rated: 50lb Fan; 50lb Fixture |
| Trade Size | 27.5 cu. in. |
| Usage | Protects Against Air Infiltration |
Comes With
| (2) | NM94 Cable Connectors |
| (1) | Mud Cover |
| (2) | Gaskets for knockouts |
| (1) | Flange Gasket |
| (1) | Box with flange |
| (1) | Adjustable steel bracket |
| (4) | #12 x 1" Long Screws |
| (2) | #10 x 2-1/2" Long Screws |
